Description
FEATURES
- Top Grade Annealed Seamless Copper Tube Manufactured to AS/NZS 1571
- 25 years product warranty on copper
- High heat resistant to 120°C to enhance the thermal conductivity performance
- Tough and durable 3 layered insulation
- UV stabilized
- Special designed insulation make it easy to feed through the wall cavity
- Suitable for all refreigerants including R32 and R410A, etc.
SPECIFICATIONS
| Copper Tube O.D. (in) | 1/2″ x 3/4″ |
| Copper Tube O.D. x Wall Thickness (mm) | 12.70 x 0.81 – 19.05 x 1.14 |
| Length (m) | 20 |
| Insulation Thickness (mm) | 10 x 10 |
| R Value | 0.45 – 0.41 |
PROPERTIES
| Copper Tube | |
| Temper | O |
| Copper Content | 99.90% min. |
| Phosphprus Content | 0.015% ~ 0.040% |
INSULATION
| Thermal Conductivity | < 0.04 W/(m*K) at 40°C |
| Permanent Deformation | 2.60% |
| Thermal Contraction | 5.80% |
| Water Absorption | Wp < 0.04 kg/㎡ |
| Vapour Diffusion | 4200μ |
| Emission of VOC | 0.00% |
